JN型系列多功能酒精回收濃縮器

JN MODEL SERIES MULTIFUNCTIONAL ALCOHOL RECOVERY CONCENTRATOR

本設備適用于中藥、西藥、葡萄糖、釀酒、淀粉、口服液、化工、食品、味精等工業酒精回收，能用于批量小、品種多的熱敏性低溫真空濃縮。

The equipment is applicable for industrial alcohol recycling of traditional Chinese medicine, Western medicine, glucose, wine brewing, starch, oral liquid, chemical industry, food and monosodium glutamate. It can be used in the low temperature vacuum concentration of heat sensitive substances with small batches and large varieties.

設備特點

1. 酒精回收：回收能力大，采用真空操作方法，改進了設備的工藝流程?；厥章誓苓_(dá)到95%，使酒精損耗率低于5%。能耗降低30%，具有投資小，回收效益高的節能設備。

2. 濃縮液料：本設備采用外加熱自然型循環式與真空負壓蒸發方式，能具有蒸發速度快，濃縮比重可達（1.4）；液料在全密封中無泡沫濃縮，用本設備濃縮出來的藥液，具有無污染，藥味濃。清洗方便，打開加熱器上下蓋即可。操作簡單，占地面積小，外形美觀，加熱器、蒸發器、保溫完整出廠，本設備與液料接觸部位均采用不銹鋼AISI304制造，保溫采用聚胺脂發泡或珍珠棉，外表面磨砂亞光處理，符合GMP醫藥標準。

EQUIPMENT CHARACTERISTICS

1. Alcohol recovery: Large recovery capacity. Adopt vacuum operation method and improve the process flow of device. The recovery rate can amount to 95%, the loss rate of alcohol is lower than 5%, and the energy consumption is 30% reduced. It is the energy saving equipment with small investment and high recovery benefit.

2. Liquid concentration: The equipment adopts external heating natural cycling mode and vacuum negative pressure evaporating mode, with instant evaporation and great concentrated specific gravity up to 1.4. The liquid materials are concentrated without foam under the completely sealed status. The liquid medicine concentrated from the equipment has no pollution, and has strong flavor of medicine. The cleaning is convenient. Just open the upper and lower covers of the heater. The operation is convenient, the space is small, the appearance is beautiful and the heater, evaporator and heat preservation are completely equipped before leaving the factory. The parts of the equipment contacting with liquid materials are made of AISI304 stainless steel. The heat preservation adopts polyurethane foaming or pearl cotton and the exterior surface adopts grinding semi-luster polishing. It is in accordance with GMP medicine standard.
